Product description
- Single gen-set controller for stand-by and prime power applications
- Direct communication with EFI engines
- All-in-one intuitive & powerful PC tool for
- configuration/monitoring/control, locally or remotely
Functionalities
- Stand-by and prime-power application in one unit
- 5 languages in the controller & Translator functionality
- 3 level of passwords
- 3 sets of alternative configurations
- ECU support & Tier 4 Final ready
- 1 slot for plug-in modules
- Fuel Pump control
- 3 analog inputs, 6 + 1 binary inputs, 6 binary outputs
- 2 higher current binary outputs
- Adjustable delay for binary inputs
- Alarms and gen-set status asignable to binary outputs
- Run Hours source ECU or internal
- Real time clock
- Multi-purpose scheduler functionality 3 maintenance timers
- Detailed history log with up to 150 records
- Possibility to disable protections
- Modbus register mapping possibility
- -20/+70 C operating temperature
- IP65 protection degree (front panel)
